Product table
Product code | Size inch |
Nozzle dia. mm |
Max wetting dia. m |
Box quantity | Box weight kg |
030 SIR 038 M04 000 | ¾” | 3,8 x 0,0 | 30,5 | 45 | 9,1 |
030 SIR 050 M04 000 | ¾” | 5,0 x 0,0 | 33,3 | 45 | 9,1 |
030 SIR 038 M04 023 | ¾” | 3,8 x 2,3 | 30,5 | 45 | 9,1 |
030 SIR 050 M04 045 | ¾” | 5,0 x 4,5 | 33,3 | 45 | 9,1 |
* Packaged with 025 SBA F04 000 F10 coded reduction coupling. Boxes include two nozzles (5,0 x 4,5) assembled with the product and two spare nozzles (3,8 x 2,3) for each product. |
Performance Table
Nozzle dia. mm |
Pressure bar |
Max wetting dia. m |
Flow rate m3/h |
Spacing mm |
Precipitation rate mm/h |
||
12 x 18 | 18 x 18 | 18 x 24 | |||||
3,8 x 0,0 | 1,5 | 24,4 | 0,72 | 3,33 | 2,22 | ||
2,0 | 27,2 | 0,79 | 3,66 | 2,44 | |||
2,5 | 28,8 | 0,82 | 3,80 | 2,53 | 1,90 | ||
3,0 | 30,0 | 0,98 | 4,54 | 3,02 | 2,27 | ||
3,5 | 30,5 | 1,06 | 4,91 | 3,27 | 4,45 | ||
5,0 x 0,0 | 1,5 | 25,8 | 1,26 | 5,83 | 3,89 | 2,92 | |
2,0 | 29,2 | 1,46 | 6,76 | 4,51 | 3,38 | ||
2,5 | 31,5 | 1,58 | 7,31 | 4,88 | 3,66 | ||
3,0 | 32,8 | 1,80 | 8,33 | 5,56 | 4,17 | ||
3,5 | 33,3 | 1,93 | 8,94 | 5,96 | 4,47 | ||
3,8 x 2,3 | 1,5 | 24,4 | 1,11 | 5,15 | 3,43 | ||
2,0 | 27,2 | 1,19 | 5,51 | 3,67 | |||
2,5 | 28,8 | 1,28 | 5,93 | 3,95 | 2,96 | ||
3,0 | 30,0 | 1,52 | 7,04 | 4,69 | 3,52 | ||
3,5 | 30,5 | 1,62 | 7,50 | 5,00 | 3,75 | ||
5,0 x 4,5 | 1,5 | 25,8 | 1,96 | 9,07 | 6,05 | 4,54 | |
2,0 | 29,2 | 2,18 | 10,09 | 6,73 | 5,05 | ||
2,5 | 31,5 | 2,50 | 7,72 | 5,79 | |||
3,0 | 32,8 | 2,78 | 8,58 | 6,44 | |||
3,5 | 33,3 | 2,98 | 9,20 | 6,90 |
